V-Knotch (V Port) Floating Ball Valve
"V" KNOTCH (V PORT) FLOATING BALL VALVE
Size Range: 25 MM TO 500 MM
DESIGN
HAND LEVER & GEAR OPERATED 2 WAY TWO PIECE DESIGN FLUSH BOTTOM “CE APPROVED” BALL VALVE WITH RPTFE SEALS FLANGE END 150#
BODY
WCB / CF8 / CF8M / CF3M
BALL
ASTM A 351 Gr. CF8 / CF8M / CF3M
STEM
AISI 304 / 316 / AISI 316L
SEAT & SEALS
METAL TO METAL
PTFE
DEVELON on request.
DESIGN & MFG STD.
BS EN ISO 17292 / ASME B 16.34
VALVE F TO F DIMENS
ANSI B 16.10
INSP. & TEST STD
BS EN 12266-I & II / API 598
PRESSURE RATING
10 KG/CM²
TEMPERATURE
UP TO 200°C
LEAKAGE CLASS
VI
END CONNECTION
FLANGE END TO ASME B 16.5 150#
BS 10 TABLE D, E, FL (customer specified.)
OPERATION
HANDLE / GEAR OPERATED
HYD. TEST PRESS.
BODY 30 KG/CM² & SEAT 5.5 KG/CM²
